Eaton Series C Complete Molded Case Circuit Breaker – Electrical Distributor

The Eaton Series C complete molded case circuit breaker, F-frame, FDC type, is a robust electrical protection device designed for industrial and commercial electrical distribution systems. It is ideal for applications involving lighting solutions, wire and cable management, and serves as a reliable component from a trusted switchgear supplier. This three-pole breaker provides fixed thermal and fixed magnetic trip protection, supporting 70 amperes at 600 Vac and 250 Vdc with high interrupting capacity, ensuring safety and operational continuity in electrical systems.

Specifications

• Manufacturer: Eaton
• Model/Series: Series C, F-frame, FDC
• Amperage: 70 amperes
• Poles: Three-pole
• Voltage Rating: 600 Vac, 250 Vdc
• Interrupting Capacity: 200 kAIC at 240 Vac, 100 kAIC at 480 Vac
• Frequency: 50/60 Hz
• Trip Type: Fixed thermal, fixed magnetic
• Dimensions (H x W x D): 6 in x 4.13 in x 3.38 in
• Weight: 4.5 lbs
• Catalog Number: FDC3070
• Mounting: Load side

Features

• Thermal-magnetic trip unit for reliable protection against overload and short circuit conditions
• Current limiting capability enhances system protection and reduces damage during faults
• Compact F-frame design allows for efficient panel space utilization
• Suitable for use in lighting and power distribution applications
• UL listed and compliant with IEC standards for safety and performance
• Factory sealed with fixed trip settings to ensure consistent operation
• Compatible with Eaton’s accessory and mounting hardware for flexible installation
