Eaton Series C complete molded case circuit breaker, F-frame, FDC, Complete breaker, Fixed thermal, fixed magnetic trip type, Three-pole, 60A, 600 Vac, 250 Vdc, 200 kAIC at 240 Vac, 100 kAIC at 480 Vac, Line and load, 50/60 Hz
SKU: #165443
Part: #FDC3060L
UPC: 786679450109
Eaton Series C complete molded case circuit breaker, F-frame, FDC, Complete breaker, Fixed thermal, fixed magnetic trip type, Three-pole, 60A, 600 Vac, 250 Vdc, 200 kAIC at 240 Vac, 100 kAIC at 480 Vac, Line and load, 50/60 Hz
SKU: #165443
Part: #FDC3060L
UPC: 786679450109
Description
Eaton Series C Complete Molded Case Circuit Breaker – Circuit Protection
The Eaton Series C complete molded case circuit breaker (MCCB), F-frame, type FDC, is designed for reliable electrical protection in industrial and commercial applications. This three-pole breaker provides fixed thermal and magnetic trip functions, supporting 60 amperes at 600 Vac and 250 Vdc. It is suited for use in electrical distribution and control panels, and is available from authorized electrical distributors and switchgear suppliers. The breaker supports line and load connections and operates at 50/60 Hz frequency, making it compatible with various power systems.
Specifications
- Manufacturer: Eaton
- Model Number: FDC3060L
- Frame: F
- Circuit Breaker Type: FDC
- Poles: Three-pole
- Amperage: 60 amperes
- Voltage Rating: 600 Vac, 250 Vdc
- Interrupt Rating: 200 kiloamps at 240 Vac, 100 kiloamps at 480 Vac
- Frequency: 50 hertz
- Dimensions (W x H x L): 4.13 in x 6 in x 3.38 in
- Product Weight: 5 lbs
Features
- Fixed thermal and magnetic trip type for dependable overcurrent protection
- Compact F-frame design suitable for various panel configurations
- High interrupting capacity enhances system safety and reliability
- Line and load terminals support flexible installation
- Designed for OEM electrical control panels and distribution equipment
