Eaton Series C complete molded case circuit breaker, F-frame, FDC, Complete breaker, Fixed thermal, fixed magnetic trip type, Three-pole, 125A, 600 Vac, 250 Vdc, 200 kAIC at 240 Vac, 100 kAIC at 480 Vac, Line and load, 50/60 Hz
SKU: #165473
Part: #FDC3125L
UPC: 786679450222
Eaton Series C complete molded case circuit breaker, F-frame, FDC, Complete breaker, Fixed thermal, fixed magnetic trip type, Three-pole, 125A, 600 Vac, 250 Vdc, 200 kAIC at 240 Vac, 100 kAIC at 480 Vac, Line and load, 50/60 Hz
SKU: #165473
Part: #FDC3125L
UPC: 786679450222
Next day delivery
Description
Eaton Series C Complete Molded Case Circuit Breaker – Electrical Distributor Circuit Protection
The Eaton Series C complete molded case circuit breaker (MCCB), F-frame, FDC type, is engineered for reliable electrical distribution and protection in commercial and industrial applications. It is designed to serve as a critical component in lighting solutions, wire and cable systems, and switchgear assemblies. This three-pole breaker supports 125 amperes with fixed thermal and magnetic trip settings, rated for 600 Vac and 250 Vdc operation, and provides high interrupting capacity to ensure system safety and continuity. Eaton's proven technology ensures compliance with global standards, making it suitable for OEMs and electrical distributors seeking robust circuit protection solutions.
- Manufacturer: Eaton
- Product Name: Eaton Series C complete molded case circuit breaker, F-frame, FDC
- Frame Size: F
- Circuit Breaker Type: FDC (Fixed thermal, fixed magnetic trip)
- Poles: Three-pole
- Amperage Rating: 125 amperes
- Voltage Rating: 600 Vac, 250 Vdc
- Interrupting Rating: 200 kiloamps (200 kAIC at 240 Vac, 100 kAIC at 480 Vac)
- Frequency: 50/60 Hz
- Dimensions (HxWxD): 4.13 in x 4.13 in x 3.38 in
- Weight: 5.0 lbs (approximate)
- Line and Load Rated
Specifications
- Fixed thermal and magnetic trip type for consistent and reliable protection
- High interrupting capacity suitable for industrial power distribution
- Compact F-frame design for space-efficient panel integration
- Compatible with Eaton’s motor operators for local and remote switching capabilities
- UL, CSA, CE, and CCC certified for global application compliance
- Robust construction with proven reliability for OEM and machinery applications
- Supports 50/60 Hz frequency for versatile use in various electrical systems
- Suitable for use in switchgear, panelboards, and busbar trunking tap-offs
