Eaton Series C FDB 110A Molded Case Circuit Breaker

The Eaton Series C complete molded case circuit breaker, F-frame, FDB type, is designed for reliable circuit protection in low voltage power distribution systems. This three-pole breaker with a fixed thermal and fixed magnetic trip type is suitable for electrical distributors and switchgear suppliers requiring dependable overload and short circuit protection. It supports load-side applications at 50/60 Hz frequency and is rated for 110 amperes at 600 Vac and 250 Vdc, making it ideal for industrial electrical systems and lighting solutions.

Specifications

• Manufacturer: Eaton
• Manufacturer Part #: FDB3110
• Amperage: 110 amperes
• Interrupt Rating: 18 kiloamps at 240 Vac, 14 kiloamps at 480 Vac
• Voltage Rating: 600 Vac, 250 Vdc
• Poles: Three-pole
• Trip Type: Fixed thermal, fixed magnetic
• Frequency: 50/60 Hz
• Dimensions (W x H x D): 5 in x 7.4 in x 4.9 in
• Product Weight: 4.3 lbs
• UPC: 786679312544

Features

• HACR rated for heating, air conditioning, and refrigeration applications
• Suitable for reverse feed use
• Thermal-magnetic trip unit provides reliable overload and short circuit protection
• Compact F-frame design supports efficient panel layouts
• Load-side connection for ease of installation
