Eaton Series C complete molded case circuit breaker, F-frame, FD, Complete breaker, Fixed thermal, fixed magnetic trip type, Two-pole, 100A, 600 Vac, 250 Vdc, 65 kAIC at 240 Vac, 35 kAIC at 480 Vac, Line and load, 50/60 Hz
SKU: #165136
Part: #FD2100L
UPC: 786679850718
Eaton Series C complete molded case circuit breaker, F-frame, FD, Complete breaker, Fixed thermal, fixed magnetic trip type, Two-pole, 100A, 600 Vac, 250 Vdc, 65 kAIC at 240 Vac, 35 kAIC at 480 Vac, Line and load, 50/60 Hz
SKU: #165136
Part: #FD2100L
UPC: 786679850718
Next day delivery
Description
Eaton Series C Complete Molded Case Circuit Breaker – Industrial Electrical Protection
The Eaton Series C complete molded case circuit breaker, F-frame, FD type, is designed for reliable branch circuit and motor protection in industrial electrical applications. This two-pole breaker supports 100 amperes at 600 Vac and 250 Vdc, with a high interrupt rating of 65 kiloamps at 240 Vac and 35 kiloamps at 480 Vac. It is suitable for use in electrical distribution systems requiring fixed thermal and magnetic trip types, providing dependable short-circuit and overload protection. Ideal for electrical distributors, lighting solutions, wire and cable systems, and switchgear suppliers, this breaker supports both line and load connections at 50/60 Hz frequency.
Specifications
- Manufacturer: Eaton
- Manufacturer Part #: FD2100L
- Frame: F
- Amperage: 100 amperes
- Number of Poles: 2
- Interrupt Rating: 65 kiloamps at 240 Vac, 35 kiloamps at 480 Vac
- Voltage Rating: 600 Vac, 250 Vdc
- Frequency: 50/60 Hz
- Dimensions (W x H x L): 2.75 in x 6 in x 3.38 in
- Product Weight: 4.5 lbs
- UPC: 786679850718
Features
- Fixed thermal and magnetic trip type for precise and reliable circuit interruption
- Line and load terminals for flexible installation
- High interrupting capacity suitable for industrial branch circuit protection
- Compact F-frame size optimized for space-saving panel designs
- Compatible with standard Eaton Series C accessories
