Eaton Series C complete molded case circuit breaker, F-frame, FD, Complete breaker, Fixed thermal, fixed magnetic trip type, Three-pole, 60A, 600 Vac, 250 Vdc, 65 kAIC at 240 Vac, 35 kAIC at 480 Vac, Line and load, 50/60 Hz
SKU: #165233
Part: #FD3060L
UPC: 786679306291
Eaton Series C complete molded case circuit breaker, F-frame, FD, Complete breaker, Fixed thermal, fixed magnetic trip type, Three-pole, 60A, 600 Vac, 250 Vdc, 65 kAIC at 240 Vac, 35 kAIC at 480 Vac, Line and load, 50/60 Hz
SKU: #165233
Part: #FD3060L
UPC: 786679306291
Next day delivery
Description
Eaton Series C Complete Molded Case Circuit Breaker – Reliable Electrical Protection
The Eaton Series C complete molded case circuit breaker (model FD3060L) is designed for industrial electrical distribution and control applications. This F-frame, three-pole breaker provides fixed thermal and fixed magnetic trip protection, suitable for both AC and DC circuits. It is rated for 60 amperes and supports voltages up to 600 Vac and 250 Vdc, making it a versatile solution for electrical distributors, lighting solutions, wire and cable systems, and switchgear suppliers requiring robust circuit protection at 50/60 Hz.
Specifications
- Manufacturer: Eaton
- Manufacturer Part #: FD3060L
- Frame: F
- Amperage: 60 amperes
- Poles: Three-pole
- Voltage Rating: 600 Vac, 250 Vdc
- Interrupting Capacity: 65 kAIC at 240 Vac, 35 kAIC at 480 Vac
- Frequency: 50 hertz
- Dimensions (HxWxL): 6 in x 4.13 in x 3.38 in
- Product Weight: 4.55 lbs
- UPC: 786679306291
Features
- Fixed thermal and fixed magnetic trip type for reliable overcurrent protection
- Line and load side connections for flexible installation
- Compact F-frame design suitable for various panel configurations
- UL and CSA listed, compliant with industry safety standards
- Designed for use in industrial control panels, electrical distribution, and OEM applications
