Eaton Series C Complete Molded Case Circuit Breaker – 90 Amp Electrical Distributor Circuit Protection

The Eaton Series C complete molded case circuit breaker (MCCB) is a three-pole, F-frame breaker designed for reliable branch circuit protection in electrical distribution and industrial applications. This 90 amp breaker features a fixed thermal and fixed magnetic trip type, suitable for load-side installation at 50/60 Hz frequency. It is engineered to provide dependable protection against overloads and short circuits, making it an essential component for electrical distributors, lighting solutions, wire and cable systems, and switchgear suppliers.

Specifications

• Manufacturer: Eaton
• Manufacturer Part #: EHD3090
• Frame Size: F
• Poles: Three-pole
• Amperage: 90 amperes
• Interrupt Rating: 18 kiloamps
• Frequency: 50 hertz
• Dimensions (H x W x D): 6 in x 4.13 in x 3.38 in
• Product Weight: 4.5 lb
• UPC: 786679317198

Features

• Fixed thermal and magnetic trip for consistent overload and short circuit protection
• Three-pole configuration for balanced three-phase circuit protection
• Compact F-frame design optimized for electrical panel integration
• Rated for 50/60 Hz operation, compatible with standard electrical distribution systems
• High interrupting capacity of 18 kA suitable for commercial and industrial power systems
• Designed to meet global certifications and standards for safety and performance
