Eaton Series C Complete Molded Case Circuit Breaker – Reliable Electrical Protection

The Eaton Series C complete molded case circuit breaker, F-frame, model EHD3050, is designed for industrial and commercial electrical distribution systems. As a fixed thermal and fixed magnetic trip type breaker, it provides dependable overcurrent protection for three-pole, 50 ampere circuits operating at 50/60 Hz. This breaker is suitable for use by electrical distributors and switchgear suppliers requiring durable and precise circuit protection solutions.

Specifications

• Manufacturer: Eaton
• Model Number: EHD3050
• Frame Size: F
• Poles: Three-pole
• Amperage Rating: 50 amperes
• Interrupting Rating: 18 kiloamps
• Frequency: 50 hertz
• Dimensions (W x H x L): 4.13 in x 6 in x 3.38 in
• Weight: 4.5 lbs
• Trip Type: Fixed thermal, fixed magnetic
• Application: Load side

Features

• Complete breaker with fixed thermal and magnetic trip for reliable protection
• Factory sealed for safety and compliance with UL489 standards
• Suitable for use in three-pole electrical distribution circuits
• Compact F-frame size optimizes panel space usage
• Designed for 50/60 Hz AC applications
• Load side installation for ease of wiring and maintenance
