Eaton Series C Complete Molded Case Circuit Breaker - 40 Ampere Circuit Protection

The Eaton Series C complete molded case circuit breaker is designed for reliable overcurrent protection in electrical distribution systems. This F-frame, three-pole breaker features fixed thermal and magnetic trip types, suitable for load-side applications at 50/60 Hz frequency. Ideal for electrical distributors and switchgear suppliers, it provides robust circuit protection for commercial and industrial electrical panels.

Specifications

• Manufacturer: Eaton
• Model Number: EHD3040
• Frame: F
• Poles: Three-pole
• Amperage: 40 amperes
• Interrupt Rating: 18 kiloamps
• Frequency: 50 hertz
• Dimensions (HxWxL): 6 in x 4.13 in x 3.38 in
• Product Weight: 4.5 lbs
• UPC: 786679317129

Features

• Complete breaker with fixed thermal and fixed magnetic trip types for reliable protection
• Load side design optimized for electrical distribution panels
• Compact F-frame size suitable for space-constrained installations
• UL489 listed and IEC 157-1 compliant for safety and performance
• Factory sealed with optional internal accessories installation prior to mounting
• Supports direct connection to multi-wire lugs for improved short-circuit current ratings and reduced panel space (refer to Eaton multi-wire lug solutions)
