Eaton Series C Complete Molded Case Circuit Breaker – Electrical Distributor and Switchgear Supplier

The Eaton Series C complete molded case circuit breaker is a three-pole, fixed thermal and fixed magnetic trip type device designed for reliable circuit protection in low voltage power distribution systems. With a 100-ampere rating and 18 kA interrupt rating at 240 Vac, this breaker is ideal for electrical distributors and lighting solutions requiring dependable protection for wire and cable installations. It supports line and load applications at 50/60 Hz frequency, making it suitable for a wide range of industrial and commercial electrical distribution panels.

Specifications

• Manufacturer: Eaton
• Manufacturer Part Number: EHD3100L
• Frame: F
• Amperage: 100 amperes
• Interrupt Rating: 18 kiloamps at 240 Vac, 14 kiloamps at 480 Vac
• Poles: Three-pole
• Trip Type: Fixed thermal, fixed magnetic
• Voltage Rating: 240 Vac / 480 Vac
• Frequency: 50 hertz
• Dimensions: Height 6 in, Width 4.13 in, Length 3.38 in
• Weight: 4.6 lbs
• Application: Line and load

Features

• Complete molded case design ensures robust protection against overload and short circuits
• Fixed thermal and magnetic trip settings provide consistent and reliable circuit interruption
• High interrupting capacity supports up to 18 kAIC at 240 Vac for enhanced safety
• Compact F-frame size optimizes panel space utilization
• Suitable for use in electrical distribution panels, lighting solutions, and wire and cable protection systems
• Compatible with Eaton’s comprehensive line of switchgear components and accessories
