Eaton Series C complete molded case circuit breaker, F-frame, EHD, Complete breaker, Fixed thermal, Fixed magnetic trip type, Single-pole, 20 A, Load side, 50/60 Hz
SKU: #164837
Part: #EHD1020
UPC: 786679317327
Eaton Series C complete molded case circuit breaker, F-frame, EHD, Complete breaker, Fixed thermal, Fixed magnetic trip type, Single-pole, 20 A, Load side, 50/60 Hz
SKU: #164837
Part: #EHD1020
UPC: 786679317327
Next day delivery
Description
Eaton Series C Complete Molded Case Circuit Breaker F-frame 20 Ampere
The Eaton Series C complete molded case circuit breaker, F-frame, EHD type, is designed for reliable circuit protection in electrical distribution systems. This single-pole, fixed thermal and magnetic trip breaker operates at 50/60 Hz frequency and is suitable for load side applications. It is engineered for use by electrical distributors, lighting solutions providers, wire and cable specialists, and switchgear suppliers requiring durable and precise circuit protection.
Specifications
- Manufacturer: Eaton
- Manufacturer Part #: EHD1020
- Frame: F
- Amperage: 20 amperes
- Frequency: 50 hertz
- Interrupt Rating: 18 kiloamps
- Dimensions (H x W x L): 6 in x 1.38 in x 3.38 in
- Product Weight: 2.0000 lbs
- UPC: 786679317327
Features
- Complete breaker with fixed thermal and magnetic trip type
- Single-pole design for precise circuit control
- Load side installation compatible
- HACR rated and suitable for reverse feed use (per Eaton F-frame circuit breaker standards)
- Compact dimensions for efficient panel space utilization
