Eaton Series C Complete Molded Case Circuit Breaker - Circuit Breaker

The Eaton Series C complete molded case circuit breaker is designed for reliable overcurrent protection in electrical distribution systems. This F-frame breaker features fixed thermal and fixed magnetic trip types, suitable for three-pole applications with a current rating of 125 amperes. It operates at 240 Vac and 125 Vdc with a high interrupt rating of 65 kiloamps at 240 Vac, 50/60 Hz. This product is ideal for electrical distributors, lighting solutions, wire and cable setups, and switchgear suppliers requiring robust circuit protection.

Specifications

• Manufacturer: Eaton
• Manufacturer Part #: ED3125
• Amperage: 125 amperes
• Voltage Rating: 240 Vac, 125 Vdc
• Interrupt Rating: 65 kiloamps
• Poles: Three-pole
• Dimensions (W x H x L): 4.13 in x 4.13 in x 3.38 in
• Product Weight: 4.5 lbs

Features

• Fixed thermal and fixed magnetic trip type for precise overcurrent protection
• Complete breaker design for easy installation and integration
• High interrupt rating enhances safety in demanding electrical environments
• Compact dimensions reduce panel space requirements
