Eaton Series C complete molded case circuit breaker - F-frame circuit breaker

The Eaton Series C complete molded case circuit breaker is a 3-pole, 15-ampere electrical protection device designed for industrial and commercial applications. This F-frame circuit breaker operates at 50/60 hertz frequency and has an interrupt rating of 35 kiloamps, making it suitable for protecting electrical distribution systems against overloads and short circuits. As a reliable component from a trusted electrical distributor and switchgear supplier, it supports safe and efficient power management in various settings.

Specifications

• Manufacturer: B-Line
• Manufacturer Part #: FD3015
• Frame: F-frame
• Amperage: 15 amperes
• Number of Poles: 3
• Frequency: 50/60 hertz
• Interrupt Rating: 35 kiloamps
• Circuit Breaker Type: FD
• Product Weight: 4.5 lbs
• UPC: 786679305607

Features

• HACR rated for heating, air conditioning, and refrigeration applications
• Thermal-magnetic trip unit offering reliable protection
• Suitable for reverse feed use
• Compatible with high intensity discharge (HID) lighting applications
• Compact F-frame design for space-efficient installation
• UL listed 100%-rated for continuous operation at full load capacity
