Specifications

• Interrupt rating: Depends on selected main circuit breaker
• Phase: Single-phase in, single-phase out
• Utility approvals: FL : MEG (Duke Energy, Florida Power, Tampa Electric, Gulf Power, Oklahoma Gas and Electric)
• Bus material: Copper
• Number of jaws: Four-jaw
• Enclosure: NEMA 3R
• Security: Ring
• Amperage Rating: 200A
• Secondary circuit breaker: BR2_, BRH2_, BRHH2_
• Type: Multiple metering
• Number of sockets: 3
• Bypass: None
• Bus Rating: 600 A
• Voltage rating: 120/240 V

General

• UPC: 782114989883
• Product Length/Depth: 12.26 in
• Product Height: 41.8 in
• Product Width: 7.01 in
• Product Weight: 54 lb
• Warranty: Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
• Certifications: UL Listed
