Description
EATON PDG23M0020TFFJ Molded Case Circuit Breaker
The EATON PDG23M0020TFFJ is a Power Defense Frame Size 2 molded case circuit breaker designed for reliable circuit protection and power distribution. Suitable for electrical distributors and switchgear suppliers, this breaker supports a range of continuous current ratings and offers fixed thermal/magnetic trip units for dependable overcurrent protection in industrial and commercial electrical systems.
Specifications
- Manufacturer: Eaton
- Manufacturer Part Number: PDG23M0020TFFJ
- Product Weight: 4.94 lbs
- Continuous Current Rating: 20 A
- Frame Size: 2 (15 A to 225 A range)
- Trip Unit Type: Fixed Thermal / Fixed Magnetic (TFF)
- Interrupting Rating (UL/CSA, 240 Vac): 65 kA rms (designator M)
- Number of Poles: 3-pole configuration
- Voltage Rating: Up to 600 Vac
- Standards and Certifications: UL, CSA, IEC (CE), CB (CCC)
- UPC: 786679279236
Features
- Frame Size 2 breakers cover current ratings from 15 A through 225 A, configurable with fixed thermal/magnetic trip units.
- Factory-configured trip unit ensures consistent and reliable protection.
- Modular accessories available for field installation or factory configuration.
- Designed and tested to meet stringent UL, CSA, IEC, and CB standards for safety and performance.
- Suitable for use in power distribution and circuit protection applications requiring fixed trip units.
