Description
EATON NGC308032E NGC 310+ 3 POLE 800A LSI English Conductors Molded Case Circuit Breaker
The Eaton NGC308032E is a 3-pole, 800 Amp molded case circuit breaker designed for electrical distribution and protection in industrial and commercial applications. It features a 310+ electronic LSI trip unit and is suitable for use by electrical distributors, lighting solutions providers, wire and cable installers, and switchgear suppliers. This circuit breaker supports high interrupting capacity and is HACR rated, ensuring reliable performance in demanding electrical systems.
Specifications
- Manufacturer: Eaton
- Manufacturer Part #: NGC308032E
- Maximum Continuous Ampere Rating: 800 A
- Number of Poles: 3
- Trip Unit: 310+ Electronic LSI
- Interrupting Capacity: 100 kA at 480 Vac or 415 Vac
- Frame Type: NG-Frame (320–1200 Amperes)
- Terminations: Imperial tapped line/load conductors
- Product Weight: 48 lbs
- UPC: 786685378992
Features
- Suitable for reverse feed use
- HACR rated for HVAC applications
- 310+ electronic trip unit provides advanced protection with LSI (Long-time, Short-time, Instantaneous) settings
- Three-pole configuration for balanced three-phase protection
- Compatible with drawout cassette systems for ease of installation and maintenance
- Designed for use in 480 Vac systems with high interrupting capacity
