Eaton molded case circuit breaker accessory motor protection, Motor circuit protector, 100 A, Three-pole, Electric starters, Frame J-K, 300-1000 A, Series C, Non-aluminum
SKU: #166560
Part: #HMCPS100R3C
UPC: 786679232668
Eaton molded case circuit breaker accessory motor protection, Motor circuit protector, 100 A, Three-pole, Electric starters, Frame J-K, 300-1000 A, Series C, Non-aluminum
SKU: #166560
Part: #HMCPS100R3C
UPC: 786679232668
Next day delivery
Description
Eaton molded case circuit breaker accessory motor protection - Motor circuit protector 100 A Three-pole
This Eaton molded case circuit breaker accessory functions as a motor circuit protector designed for electrical distribution and control applications. It is suitable for use with electric starters and is part of the Frame J-K series, compatible with 300-1000 A Series C switchgear. This three-pole device provides reliable motor protection at 100 amperes, making it an essential component for electrical distributors and switchgear suppliers in industrial and commercial settings.
Specifications
- Manufacturer: Eaton
- Manufacturer Part #: HMCPS100R3C
- Amperage: 100 amperes
- Frame: Frame J-K
- Poles: Three-pole
- Dimensions (L x W x H): 7.25 in x 5 in x 5 in
- Product Weight: 4.5 lbs
- UPC: 786679232668
Features
- Motor circuit protection accessory compatible with Eaton molded case circuit breakers
- Designed for use with electric starters in motor control applications
- Supports three-pole configuration for balanced motor protection
- Frame J-K compatibility ensures integration with 300-1000 A Series C switchgear
- Non-aluminum construction suitable for robust electrical environments
