EATON HFD3040L HFD BKR 3P 40A C/W LINE & LOAD TERMINALS
SKU: #411352
Part: #HFD3040L
UPC: 786679175118
EATON HFD3040L HFD BKR 3P 40A C/W LINE & LOAD TERMINALS
SKU: #411352
Part: #HFD3040L
UPC: 786679175118
Description
EATON HFD3040L Molded Case Circuit Breaker for Electrical Distribution
The Eaton HFD3040L is a 3-pole, 40 amp thermal-magnetic molded case circuit breaker designed for electrical distribution and protection in commercial and industrial applications. It is suitable for use by electrical distributors, lighting solutions providers, wire and cable suppliers, and switchgear suppliers requiring reliable circuit protection. This breaker includes line and load terminals, supports up to 600 VAC and 250 VDC, and features a high interrupting capacity of 65 kAIC at 480 VAC.
Specifications
- Manufacturer: Eaton
- Catalog Number: HFD3040L
- Poles: 3
- Amperage Rating: 40 A
- Voltage Rating: 600 VAC / 250 VDC
- Interrupting Capacity: 65 kAIC at 480 VAC
- Terminal Type: Line and Load terminals
- Product Weight: 4.55 lbs
- UL Listed: UL489 compliant
- IEC Compliance: IEC 157-1
Features
- Thermal-magnetic trip unit providing reliable overcurrent protection
- Non-interchangeable trip units for consistent performance
- Terminals designed for copper and aluminum conductors with recommended torque values
- Suitable for reverse feed applications
- Factory sealed design with options for internal accessories installation
- Manual operation via handle with push-to-trip test button for functional verification
- High interrupting rating suitable for use in branch circuit and feeder applications
- Compatible with Eaton’s mounting hardware and accessories for ease of installation
