EATON GHB3035 GHB 3P 35A 480/277V Breaker - Molded Case Circuit Breaker

The Eaton GHB3035 is a three-pole, 35 ampere molded case circuit breaker designed for use in electrical distribution systems. It provides reliable thermal-magnetic protection for circuits with voltage ratings up to 480/277 volts AC. This breaker is suitable for use in panelboards and switchgear supplied by electrical distributors and lighting solutions providers requiring dependable circuit protection. It is compatible with copper or aluminum conductors and supports wire sizes from 14 to 3 AWG.

Specifications

• Manufacturer: Eaton
• Catalog Number: GHB3035
• Poles: 3
• Continuous Ampere Rating: 35 A
• Voltage Rating: 480/277 V AC
• Interrupting Capacity: 14 kA at 480Y/277 V AC
• Wire Type: Copper/Aluminum
• Wire Size Range: 14‚Äì3 AWG
• Terminal Type: Pressure (steel body), slotted screw head
• Operating Temperature: 40 ¬∞C continuous rating
• Product Weight: 1.75 lbs
• UPC: 786679172605

Features

• Thermal-magnetic trip unit for reliable overcurrent protection
• Non-interchangeable trip units to ensure circuit-specific protection
• UL 489 listed with interrupting capacity suitable for commercial and industrial applications
• Suitable for use in three-phase panelboards and switchgear applications
• Factory sealed for safety and compliance with Underwriters Laboratories standards
• Compatible with Eaton power line 2 type panelboards
• Torque values for terminal connections optimized for secure wiring
