Eaton General duty non-fusible safety switch, single-throw, 200 A, NEMA 3R, Rainproof, Painted galvanized steel, Three-pole, Three-wire, 240 V
SKU: #162860
Part: #DG324URK
UPC: 782113213576
Eaton General duty non-fusible safety switch, single-throw, 200 A, NEMA 3R, Rainproof, Painted galvanized steel, Three-pole, Three-wire, 240 V
SKU: #162860
Part: #DG324URK
UPC: 782113213576
Description
Eaton General duty non-fusible safety switch, single-throw, 200 A, NEMA 3R, Rainproof, Painted galvanized steel, Three-pole, Three-wire, 240 V - Safety Switch
This Eaton general duty non-fusible safety switch is designed for reliable electrical distribution and control in commercial and industrial applications. It features a single-throw mechanism rated at 200 amperes, suitable for 240 V three-wire systems. The switch is housed in a rainproof NEMA 3R enclosure made of painted galvanized steel, providing robust protection against environmental elements. Ideal for electrical distributors and switchgear suppliers, this switch supports safe and efficient power isolation in lighting solutions, wire and cable installations, and other electrical distribution systems.
Specifications
- Manufacturer: Eaton
- Manufacturer Part #: DG324URK
- Amperage: 200 amperes
- Voltage: 240 V
- Number of Poles: Three-pole
- Number of Wires: Three-wire
- Enclosure Rating: NEMA 3R (Rainproof)
- Enclosure Material: Painted Galvanized Steel
- Dimensions (W x H x D): 16 in x 25.5 in x 11.25 in
- Product Weight: 55 lbs
- Switch Type: Single-throw
- UPC: 782113213576
Features
- Non-fusible design for general duty applications
- Rainproof NEMA 3R enclosure suitable for outdoor use
- Painted galvanized steel enclosure offers corrosion resistance
- Three-pole, three-wire configuration for versatile electrical setups
- Compact dimensions for ease of installation in electrical distribution panels
- Factory-installed ground lug for enhanced safety
