Eaton Edison MEN fuse, Time-delay Midget fuse, Supplemental protection of small motors, transformers, solenoids, and other high inrush power electronic circuits, 15 A, Dual, Non-indicating, 10 kAIC at 125 Vac, Fiber tube, Standard, 250 V
SKU: #334214
Part: #MEN15
UPC: 782634521501
Eaton Edison MEN fuse, Time-delay Midget fuse, Supplemental protection of small motors, transformers, solenoids, and other high inrush power electronic circuits, 15 A, Dual, Non-indicating, 10 kAIC at 125 Vac, Fiber tube, Standard, 250 V
SKU: #334214
Part: #MEN15
UPC: 782634521501
Description
Eaton Edison MEN Time-delay Midget Fuse 15 Ampere
This Eaton Edison MEN time-delay midget fuse provides supplemental protection for small motors, transformers, solenoids, and other high inrush power electronic circuits. Designed for use in electrical distribution and lighting solutions, it ensures reliable circuit protection with a 10 kA interrupting rating at 125 Vac. The fuse features a fiber tube construction and dual non-indicating ends, suitable for various industrial and commercial electrical applications.
Specifications
- Amperage: 15 amperes
- Voltage Rating: 250 V
- Interrupting Rating: 10 kAIC at 125 Vac
- Material: Fiber
- Length: 1 in
- Width: 0.406 in
- Height: 0.406 in
- Product Weight: 0.2000 lb
- Manufacturer Part #: MEN15
- UPC: 782634521501
Features
- Time-delay design for protection of high inrush current devices
- Dual non-indicating ends for reliable circuit interruption
- Fiber tube construction for durability and safety
- Standard size for compatibility with Eaton Edison fuse holders
