Eaton Definite purpose control contactor, Non-reversing, Four-pole, 30A, 110-120 Vac, 50/60 Hz, Open with metal mounting plate, Screw/pressure plate and quick connect terminals (side-by-side), 30A IFL, 40A RL
SKU: #160858
Part: #C25END430A
UPC: 782113542331
Eaton Definite purpose control contactor, Non-reversing, Four-pole, 30A, 110-120 Vac, 50/60 Hz, Open with metal mounting plate, Screw/pressure plate and quick connect terminals (side-by-side), 30A IFL, 40A RL
SKU: #160858
Part: #C25END430A
UPC: 782113542331
Description
Eaton Definite Purpose Control Contactor 30A – Electrical Distributor Motor Control
The Eaton Definite Purpose Control Contactor, model C25END430A, is a non-reversing, four-pole contactor designed for motor control and protection applications. It operates at 30 amperes with a coil voltage of 110-120 Vac, 50/60 Hz. This device is suitable for use by electrical distributors and switchgear suppliers requiring reliable control components for industrial and commercial motor control panels. Its open enclosure with a metal mounting plate and screw/pressure plate plus quick connect terminals provide flexible and secure wiring options.
Specifications
- Manufacturer: Eaton
- Manufacturer Part #: C25END430A
- Frame: 25-40 amperes
- Amperage: 30 amperes
- Number of Poles: 4
- Coil Voltage: 110/120 volts AC, 50/60 Hz
- Enclosure Type: Open with metal mounting plate
- Connection Type: Quick connect terminals (side-by-side)
- Dimensions (W x H x L): 2.68 in x 3.75 in x 3.38 in
- Product Weight: 2.0 lbs
- UPC: 782113542331
Features
- Non-reversing four-pole design for motor control applications
- Open construction with metal mounting plate for easy installation
- Screw/pressure plate main terminals accommodate #8–#14 AWG copper wire
- Quick connect coil terminals accept #12–#16 AWG copper wire or .250 x .032 quick connect
- Compact size suitable for control panels with space constraints
- Designed for 30A continuous current with 30A interrupting fault level (IFL) and 40A resistive load (RL)
