Eaton Crouse-Hinds series Cam-Lok J Series E1016 insulated receptacle, Up to 400A continuous, #2-4/0 AWG, Orange, Male, Thermoplastic elastomer (TPE), Double hole bus bar, 600 Vac/dc
SKU: #130180
Part: #E1016-1703BB
UPC: 662275925466
Eaton Crouse-Hinds series Cam-Lok J Series E1016 insulated receptacle, Up to 400A continuous, #2-4/0 AWG, Orange, Male, Thermoplastic elastomer (TPE), Double hole bus bar, 600 Vac/dc
SKU: #130180
Part: #E1016-1703BB
UPC: 662275925466
Next day delivery
Description
Eaton Crouse-Hinds Cam-Lok J Series E1016 Insulated Receptacle - 400A Electrical Connector
The Eaton Crouse-Hinds Cam-Lok J Series E1016 insulated receptacle is designed for industrial power distribution applications requiring reliable, quick, and tool-free electrical connections. Suitable for use by electrical distributors and switchgear suppliers, this connector supports up to 400 amperes continuous current and accepts wire sizes from #2 to 4/0 AWG. Its thermoplastic elastomer (TPE) construction offers durability and resistance to heat, weather, ozone, oil, and abrasion, making it ideal for lighting solutions, wire and cable connections, and portable power distribution systems.
Specifications
- Amperage: 400 amperes
- Voltage Rating: 600 VAC/DC
- Cable Size: #2 - 4/0 AWG
- Material: Thermoplastic Elastomer (TPE)
- Color: Orange
- Dimensions (L x W x H): 4.44 in x 2.25 in x 2.25 in
- Environmental Rating: NEMA 3R
- Operating Temperature Range: -40ºC to 105ºC
- Manufacturer Part #: E1016-1703BB
Features
- Double cam principle provides a positive, vibration-proof connection
- Self-compensating for wear to maintain reliable contact
- No moving contact surfaces, eliminating arcing or burning
- Contacts machined from high conductivity brass for smooth sliding fit and easy locking action
- Watertight elastomeric insulator molded from colorfast material, color-coded for phase identification
- Recessed contacts protected by insulating jacket extending beyond contact ends for safety
- Integrated strain relief system with retaining wire to prevent cable jacket pull-away and bare conductor exposure
- High strength molded-in-place locking ring secures insulator to contact
- Fully insulated for direct mounting to steel panels
- Double hole bus bar termination for added strength
- Snapback covers provide NEMA 3R environmental seal
- High impact-resistant thermoplastic housing protects receptacles from damage
- Easy assembly and disassembly without tools
- Accepts a wide range of cable sizes from #2 to 4/0 AWG
