Eaton CN35 electrically held lighting contactor, 20 A, 120 V/60 Hz, 110 V/50 Hz, 20 A, NEMA 1, Painted steel, 45 mm, Six-pole, A202 Series, Non-combination electrically and mechanically held
SKU: #164505
Part: #ECL03B1A6A
UPC: 782114152683
Eaton CN35 electrically held lighting contactor, 20 A, 120 V/60 Hz, 110 V/50 Hz, 20 A, NEMA 1, Painted steel, 45 mm, Six-pole, A202 Series, Non-combination electrically and mechanically held
SKU: #164505
Part: #ECL03B1A6A
UPC: 782114152683
Next day delivery
Description
Eaton CN35 Electrically Held Lighting Contactor - Lighting Control Solutions
The Eaton CN35 electrically held lighting contactor is designed for reliable lighting control applications in commercial and industrial environments. It is suitable for use by electrical distributors and switchgear suppliers offering lighting solutions and wire and cable installations. This six-pole contactor operates at 20 amperes with coil voltages of 120 V/60 Hz or 110 V/50 Hz and features a painted steel enclosure rated NEMA 1. The CN35 is ideal for controlling lighting loads where it is not critical for contacts to remain closed during loss of control power, making it appropriate for various lighting control needs.
Specifications
- Amperage: 20 amperes
- Coil Voltage: 120 volts (60 Hz) / 110 volts (50 Hz)
- Enclosure Material: Painted Steel
- Frame Size: 45 millimeters
- Poles: Six-pole
- Dimensions (H x W x L): 9 in x 2.1 in x 2.1 in
- Manufacturer: Eaton
- Manufacturer Part Number: ECL03B1A6A
- NEMA Rating: NEMA 1
- Product Weight: 0.35 lbs
Features
- Electrically held operation with continuous control power applied during operation
- Suitable for lighting control applications where contacts do not need to stay closed during power loss
- Compact and rugged painted steel enclosure for indoor use (NEMA 1)
- Six-pole configuration for versatile lighting circuit control
- Compatible with standard wiring practices for lighting contactors
- Designed for use in lighting control panels, switchgear assemblies, and electrical distribution systems
