Eaton CH thermal magnetic circuit breaker,70 A,10 kAIC,Two-pole,120/240 V,#8-2 AWG,CHB,CH Loadcenters
SKU: #161965
Part: #CHB260
UPC: 782113112527
Eaton CH thermal magnetic circuit breaker,70 A,10 kAIC,Two-pole,120/240 V,#8-2 AWG,CHB,CH Loadcenters
SKU: #161965
Part: #CHB260
UPC: 782113112527
Description
Eaton CH Thermal Magnetic Circuit Breaker 70 A 10 kAIC Two-Pole 120/240 V
The Eaton CH thermal magnetic circuit breaker is engineered for reliable circuit protection in low voltage electrical distribution systems. Designed for use in residential and light commercial applications, it offers dependable overload and short-circuit protection. Suitable for panelboards, loadcenters, and motor control centers, this circuit breaker supports wire sizes from #8 to 2 AWG and operates at 120/240 volts with a 10 kiloamp interrupt rating. Eaton is a trusted electrical distributor and switchgear supplier known for quality lighting solutions and wire and cable products.
Specifications
- Manufacturer: Eaton
- Manufacturer Part #: CHB260
- Amperage: 60 amperes
- Interrupt Rating: 10 kiloamps
- Number of Poles: 2
- Voltage: 120/240 V
- Dimensions (W x H x L): 1.5 in x 2.7 in x 3.4 in
- Product Weight: 0.55 lbs
- UPC: 782113112527
Features
- Thermal magnetic trip mechanism for accurate overload and short circuit protection
- Two-pole design for 120/240 V applications
- Rated for wire sizes #8 to 2 AWG
- 10 kA interrupting capacity suitable for typical residential and light commercial loadcenters
- Compact form factor for easy installation in CH Loadcenters and panelboards
