Eaton CC enclosed breaker,Molded case breaker,High interrupting capacity,200 A,100 kAIC,Three-pole,240 V,!,#2/0 AWG-300 kcmil Cu/Al,CCH,Type ECC Unit enclosures,120 V Shunt trip
SKU: #161226
Part: #CCH3200
UPC: 782113338606
Eaton CC enclosed breaker,Molded case breaker,High interrupting capacity,200 A,100 kAIC,Three-pole,240 V,!,#2/0 AWG-300 kcmil Cu/Al,CCH,Type ECC Unit enclosures,120 V Shunt trip
SKU: #161226
Part: #CCH3200
UPC: 782113338606
Description
Eaton CC Enclosed Breaker Molded Case Breaker 200 A High Interrupting Capacity
The Eaton CC enclosed breaker is a high interrupting capacity molded case circuit breaker designed for reliable electrical distribution and protection in residential and light commercial applications. It is suitable for use by electrical distributors, lighting solutions providers, wire and cable suppliers, and switchgear suppliers requiring robust circuit protection at 240 V with a 200 ampere rating. The breaker supports three-pole configurations and accommodates #2/0 AWG to 300 kcmil copper or aluminum conductors. It includes a type ECC unit enclosure with a 120 V shunt trip feature for enhanced control options.
Specifications
- Manufacturer: Eaton
- Manufacturer Part #: CCH3200
- Product Weight: 4.2 lbs
- Amperage: 200 amperes
- Circuit Breaker Type: CCH
- Interrupting Capacity: 100 kAIC
- Poles: Three-pole
- Voltage: 240 V
- Wire Size Range: #2/0 AWG to 300 kcmil Cu/Al
- Dimensions (W x H x D): 5.7 in x 5.2 in x 7.7 in
Features
- High interrupting capacity rated at 100 kAIC for enhanced safety and performance
- Enclosed breaker design suitable for use as a service disconnect or sub-panel protection
- Supports three-pole configuration for three-phase power distribution
- Includes 120 V shunt trip for remote breaker control
- Compatible with #2/0 AWG to 300 kcmil copper or aluminum conductors
- Compact dimensions for flexible installation in residential and light commercial loadcenters
