Eaton Bussmann series FRN-R fuse, 25 A, Dual, Class RK5, Non-indicating, Ferrule end x ferrule end, 8 sec at 500%, 20 kAIC at 125 Vdc,200 kAIC at 250 V, Standard, 250 V, 125 Vdc
SKU: #333558
Part: #FRN-R-25
UPC: 051712507332
Eaton Bussmann series FRN-R fuse, 25 A, Dual, Class RK5, Non-indicating, Ferrule end x ferrule end, 8 sec at 500%, 20 kAIC at 125 Vdc,200 kAIC at 250 V, Standard, 250 V, 125 Vdc
SKU: #333558
Part: #FRN-R-25
UPC: 051712507332
Total Price: $17.67 per each Sold in increments of 1 each
Description
Eaton Bussmann series FRN-R fuse 25 A - Class RK5 Electrical Protection
The Eaton Bussmann series FRN-R fuse is a Class RK5 dual-element, time-delay fuse designed for advanced electrical protection in industrial and commercial applications. It provides reliable motor overload, ground fault, and short-circuit protection. This fuse is suitable for use in circuits subject to temporary motor overloads and surge currents, making it ideal for electrical distributors and switchgear suppliers managing motor control and power distribution systems.
Specifications
- Amperage: 25 amperes
- Voltage Rating: 250 Vac / 125 Vdc
- Interrupting Rating: 200 kA at 250 V, 20 kA at 125 Vdc
- Fuse Class: Class RK5
- Connection Type: Ferrule end x ferrule end
- Dimensions (L x W x H): 3 in x 0.81 in x 0.81 in
- Time-Delay: 8 seconds at 500% of rated current
- Manufacturer Part Number: FRN-R-25
- Product Weight: 1.95 lbs
Features
- Dual-element design for high performance short-circuit and overload protection
- Provides motor overload and ground fault protection to prevent motor burnout
- Time-delay feature allows temporary motor startup surges without nuisance blowing
- Helps prevent burnout from single-phasing on three-phase motor systems
- Simplifies blackout prevention through selective coordination
- Current-limiting fuse reduces let-through energy to protect downstream components
- Ferrule end connections ensure secure and reliable installation
