Eaton BR thermal magnetic circuit breaker,Type BR 1-Inch plug-on shunt trip circuit breaker,20 A,10 kAIC,Two-pole,120/240V,BR,Common breaker trip,#14-4 AWG Cu/Al,Q28,BR,Type BR Loadcenters,Shunt trip included
SKU: #159601
Part: #BR220ST
UPC: 786676000291
Eaton BR thermal magnetic circuit breaker,Type BR 1-Inch plug-on shunt trip circuit breaker,20 A,10 kAIC,Two-pole,120/240V,BR,Common breaker trip,#14-4 AWG Cu/Al,Q28,BR,Type BR Loadcenters,Shunt trip included
SKU: #159601
Part: #BR220ST
UPC: 786676000291
Next day delivery
Description
Eaton BR Thermal Magnetic Circuit Breaker - 20 Amp Two-Pole Circuit Breaker
The Eaton BR thermal magnetic circuit breaker, model BR220ST, is a two-pole, 20-amp, 10 kAIC rated device designed for use in 120/240V electrical systems. This Type BR 1-inch plug-on shunt trip circuit breaker is suitable for residential and light commercial applications, providing reliable branch circuit protection. It is compatible with BR Type BR Loadcenters and supports #14-4 AWG copper/aluminum wire connections. Eaton, a trusted electrical distributor and switchgear supplier, offers this breaker as part of its comprehensive lighting solutions and wire and cable product lines.
Specifications
- Manufacturer: Eaton
- Manufacturer Part #: BR220ST
- Amperage: 20 amperes
- Number of Poles: 2
- Interrupt Rating: 10 kiloamps
- Voltage: 120/240V
- Dimensions (W x H x L): 4.25 in x 4 in x 4.5 in
- Wire Size Range: #14-4 AWG Cu/Al
- Weight: 1.0000 lb
- UPC: 786676000291
Features
- Thermal magnetic trip providing reliable overload and short circuit protection
- Plug-on design for easy installation in Type BR Loadcenters
- Shunt trip included for remote tripping capability
- Common breaker trip for multipole coordination
- Compatible with #14-4 AWG copper and aluminum wiring
- Rated for 10 kAIC interrupt capacity ensuring safe interruption of fault currents
- Compact 1-inch width saves panel space
