Eaton BR main breaker loadcenter, No feed-thru lugs, Main circuit breaker CC, 200 A, L1, Aluminum, Cover included, NEMA 1, Metallic, 25 kAIC, 42-Ckt, 30 Spaces, 4-wire, Three-phase, #1 AWG-250 kcmil Cu/Al, Combination, 208 Y/120, 240 V
SKU: #157577
Part: #3BR3042B200
UPC: 786676440707
Eaton BR main breaker loadcenter, No feed-thru lugs, Main circuit breaker CC, 200 A, L1, Aluminum, Cover included, NEMA 1, Metallic, 25 kAIC, 42-Ckt, 30 Spaces, 4-wire, Three-phase, #1 AWG-250 kcmil Cu/Al, Combination, 208 Y/120, 240 V
SKU: #157577
Part: #3BR3042B200
UPC: 786676440707
Next day delivery
Description
Eaton BR Main Breaker Loadcenter – 200 Amp Electrical Panel
The Eaton BR main breaker loadcenter is a three-phase electrical distribution panel designed for light commercial and residential applications. It features a 200 amp main circuit breaker with a 25 kAIC interrupting rating, suitable for 208Y/120 or 240 V systems. This loadcenter supports up to 42 circuits and 30 spaces, providing flexible wiring options with a combination mounting type. The panel is constructed with a metallic enclosure and aluminum bus material, ensuring durability and reliable conductivity. It is ideal for use by electrical distributors, lighting solutions providers, wire and cable suppliers, and switchgear suppliers requiring robust and code-compliant power distribution equipment.
Specifications
- Manufacturer: Eaton
- Model Number: 3BR3042B200
- Main Breaker Amperage: 200 amperes
- Number of Circuits: 42
- Number of Spaces: 30
- Number of Phases: 3
- Bus Material: Aluminum
- Mounting Type: Combination (flush/surface)
- Enclosure Material: Metallic
- Voltage Rating: 208Y/120 or 240 V
- Interrupting Rating: 25 kAIC
- Dimensions (W x H x D): 14.31 in x 4.5 in x 3.88 in
- Wire Size Range: #1 AWG to 250 kcmil Cu/Al
Features
- Main circuit breaker provides reliable overcurrent protection for the entire panel
- Combination mounting type allows for flexible installation options
- Aluminum bus offers excellent conductivity and corrosion resistance
- Metallic enclosure ensures durability and compliance with NEMA 1 standards
- Supports three-phase power distribution for commercial and industrial applications
- Accepts plug-on Type BR branch circuit breakers for easy installation and expansion
- Compact design suitable for flush mounting within standard stud widths
- 25 kAIC interrupting rating for enhanced safety and code compliance
- Includes cover for protection and aesthetic finish
