Eaton BR convertible loadcenter,No feed-thru lugs, includes BREQS125 hold-down screw,Convertible main,100 A,D1,Aluminum,Cover included,NEMA1,Metallic,10 kAIC,BR,Surface,30 Circuits,30 Spaces,Four-wire,Three-phase,208 Y/120, 240 V
SKU: #157557
Part: #3BR3030N100S
UPC: 786676443005
Eaton BR convertible loadcenter,No feed-thru lugs, includes BREQS125 hold-down screw,Convertible main,100 A,D1,Aluminum,Cover included,NEMA1,Metallic,10 kAIC,BR,Surface,30 Circuits,30 Spaces,Four-wire,Three-phase,208 Y/120, 240 V
SKU: #157557
Part: #3BR3030N100S
UPC: 786676443005
Description
Eaton BR Convertible Loadcenter – 100 A Three-Phase Electrical Distributor Solution
The Eaton BR convertible loadcenter is a robust electrical distribution panel designed for commercial and industrial applications requiring reliable power distribution with flexibility in wiring configurations. This loadcenter supports 3-phase, 208Y/120 or 240 V systems, making it suitable for a variety of lighting solutions, wire and cable installations, and switchgear supplier requirements. It is engineered for surface mounting and includes a metallic enclosure with a NEMA 1 rating, ensuring durability and protection in indoor environments.
Specifications
- Manufacturer: Eaton
- Amperage: 100 amperes
- Number of Phases: 3
- Number of Circuits: 30
- Number of Spaces: 30
- Interrupt Rating: 10 kiloamps (kAIC)
- Bus Material: Aluminum
- Enclosure Material: Metallic
- Mounting Type: Surface
- Dimensions (W x H x D): 14.31 in x 29.13 in x 3.88 in
- Voltage Rating: 208Y/120, 240 V
- Weight: 31 lbs
- UPC: 786676443005
- Manufacturer Part #: 3BR3030N100S
- Color: Metallic
- Cover: Included
- Series: BR
Features
- Convertible main with no feed-thru lugs for flexible installation
- Includes BREQS125 hold-down screw for secure breaker mounting
- Rated for 30 circuits and 30 spaces to accommodate multiple branch circuits
- Aluminum bus provides superior conductivity and corrosion resistance
- Surface mount design for easy installation in commercial environments
- 10 kAIC interrupt rating suitable for light commercial projects
- Compatible with Eaton BR series plug-on branch breakers
- Metallic NEMA 1 enclosure provides protection suitable for indoor use
