Eaton 3MM residential meter stack, Multiple metering, 125A, Copper, Bus:800A, No bypass, Indoor, Depends on selected MCB, Five-jaw, Sockets:2, Three-phase in, single-phase out, B-C, BR2_, BRH2_, BRHH2_, BRX2, Ring, Socket:125A, 120/208 Vac
SKU: #157853
Part: #3MM212C2BC
UPC: 782114631904
Eaton 3MM residential meter stack, Multiple metering, 125A, Copper, Bus:800A, No bypass, Indoor, Depends on selected MCB, Five-jaw, Sockets:2, Three-phase in, single-phase out, B-C, BR2_, BRH2_, BRHH2_, BRX2, Ring, Socket:125A, 120/208 Vac
SKU: #157853
Part: #3MM212C2BC
UPC: 782114631904
Description
Eaton 3MM Residential Meter Stack, Multiple Metering, 125A, Copper Bus:800A, Indoor - Electrical Metering Solutions
The Eaton 3MM residential meter stack is designed for multiple metering applications in indoor environments. It supports 125 ampere sockets with a copper bus rated at 800 amperes, suitable for residential electrical distribution. This meter stack accommodates five-jaw sockets with a two-socket configuration, enabling three-phase input and single-phase output. It is ideal for electrical distributors and switchgear suppliers requiring reliable, compact metering solutions for residential wire and cable systems.
Specifications
- Product Name: Eaton 3MM residential meter stack, Multiple metering, 125A, Copper, Bus:800A, No bypass, Indoor, Depends on selected MCB, Five-jaw, Sockets:2, Three-phase in, single-phase out, B-C, BR2_, BRH2_, BRHH2_, BRX2, Ring, Socket:125A, 120/208 Vac
- Manufacturer: Eaton
- Manufacturer Part #: 3MM212C2BC
- Bus Ampacity: 800 Amperes
- Socket Ampere Rating: 125 Amperes
- Sockets: 2
- Weight: 52 lbs
- Dimensions (W x H x L): 7.01 in x 41.8 in x 12.26 in
- Voltage: 120/208 Vac
- Application: Indoor use
- Metering Type: Multiple metering, three-phase in, single-phase out
Features
- Copper bus rated for 800 amperes providing high conductivity and durability
- Multiple metering configuration for residential applications
- Five-jaw sockets for secure electrical connections
- Two socket positions supporting 125 ampere metering
- Indoor rated enclosure suitable for residential electrical distribution
- Compatible with BR2_, BRH2_, BRHH2_, BRX2 circuit breakers
- Designed for three-phase input and single-phase output metering
