Features

• Photocell Uses Photopic Curve to Accurately Measure Light as it is Perceived by the Human Eye
• Provide Precise Control of Lighting to Maintain Desired Light Level
• Separate Handheld Remote Control for Setup Prevents Tampering
• Boosts Energy Savings by Reducing Maximum Lamp Output Often Resulting in a 20% Reduction or More Compared with Lights at Full Output
• Achieves Lumen Maintenance by Holding Target Light Level as Lamp Output Decreases over Time
• Sliding Set Point Control Algorithm

Additional Information

• Sensitivity Adjustment PIR (High/Low), Ultrasonic (Fully Variable)

Specifications

• Type: Sensor with Dual Relay
• Sensor Type: Passive Infrared, Ultrasonic
• Voltage Rating: 120/277 VAC at 50/60 Hz
• Load Type: Ballast/Tungsten
• Load Rating: 0 to 800 W at 120 VAC (Ballast/Tungsten), 0 to 1200 W at 277 VAC (Ballast), 1/6 HP at 277 VAC (Ballast)
• Area Coverage: 35 Ft x 30 Ft PIR, 20 Ft x 20 Ft Ultrasonic (Major Motion), 20 Ft x 15 Ft PIR, 15 Ft x 15 Ft Ultrasonic (Minor Motion)
• Time Delay: 5/15/30 Min
• Wall Plate Type: Decorator
• Terminal Type: Neutral Wire
• Finish: Light Almond
• Mounting: Wall
• Size: 2.73 Inch L x 1.76 Inch W x 1.83 Inch D
• Application: Lunch/Break Room, Small/Executive Office, Small/Medium Conference Room
• Approval: CUL
