Features

• Versatile and reusable set-screw connectors made of 6061T-6 aluminum alloy
• Electro-tin plated for low contact resistance
• For use with copper or aluminum conductors

Certifications and Standards

• cULus
• UL Listed
• UL 486A-486B

Specifications

• Country of Origin: United States
• Length: 3.250 in
• Width: 3.190 in
• Height: 1.88 in
• Mounting Base: No
• Wire Range: 1000 MCM - 350 MCM
• Field Application: Terminate
• FINISH: Tin Plated
• Future Plan: Rebrand as Polaris
• Hex Wrench Size: 9/16 IN
• INNER HEIGHT: 2.8500
• INNER LENGTH: 5.8000
• INNER WEIGHT: 1.7900
• INNER WIDTH: 4.3500
• MATERIAL: 6061T-6 Aluminum Alloy
• Max Temperature: 90 C
• Mounting Hole Position: 0.880 IN
• Number of Conductors/Circuits/Terminals: 2
• Product Assortment: Aluminum Mechanical Terminations
• Product Series: 2-T
• Tang Thickness: 0.44 IN
• Tang Width: 3.19 IN
• VOLTAGE RATING: 600 V
• WARRANTY: 1 Year
• Tang Length: 1.75 IN
• Conductor Type: Copper, Aluminum
