Features

• Clamp Meter with automatically ranging true mean squared (TRMS) technology for increased accuracy
• Test leads measure AC/DC voltage, resistance, continuity, frequency and capacitance and tests diodes
• Thermocouple probe measures temperature
• Low Impedance (LoZ) mode for identifying and eliminating ghost or stray voltages
• CAT IV 600V, CAT III 1000V, Class 2, Double insulation safety rating
• Built to withstand a 6.6-Foot (2m) drop
• Low battery indicator and easily accessible battery compartment
• Operating temp - 32-degree F to 104-degree F (0-degree C to 40-degree C)
• Operating altitude to 6562-Foot (2000m)
• Includes carrying pouch, test leads, thermocouple with adapter and batteries
• Meets requirements for use in basic and controlled electromagnetic environments like residential, office and light-industrial locations
• Features Low Battery Indicator and Auto Shut Off

Warnings

• Do not attempt to measure resistance or continuity on live circuits.
• Read, understand and follow all instructions, cautions and warnings attached to and /or packed with all test and measurement devices before each use.
• Before each use verify meter operation by measuring a known voltage or current.
• Do not use the meter during electrical storms or in wet weather, and do not use the meter or test leads if they appear to be damaged.

Specifications

• Overall Height: 1.55" (3.9 cm)
• Drop Protection: 6.6' (2 m)
• Frequency: 1Hz - 500 KHz
• Standard: CAT IV 600V; CE Certified
• Functions: Test leads measure AC/DC voltage, resistance, continuity, frequency and capacitance and tests diodes. Thermocouple probe measures temperature.
• Voltage: 1000V AC; 1000V DC
• Included: Digital Clamp Meter; Carrying Case; 41" (1041.4 mm) Test Leads; Thermocouple with Adapter; Batteries
• Capacitance: 6000µF
• Temperature Range: -14° - 1000°F (-26° - 538°C)
• Application: Measures Current
• Ingress Protection: IP40
• Overall Width: 3.81" (9.7 cm)
• Batteries: 2 x AAA
• Current: 600A AC; 600A DC
• Display: 6000 Count LCD
• Overall Length: 9.09" (23.1 cm)
• Jaw Size: 1.38" (3.5 cm)
• Ohms (Resistance): 60MO
• Height: 1.5400 in
• Width: 3.8200 in
• Depth: 9.0900 in
• Weight: 0.7810 lbs
