DCLV1-I, Decorator Lighting Dimmer Controller for 0-10V Dimming

The DCLV1-I is a low voltage (Class 2) 0-10V Controller designed for precise dimming control in lighting applications. It supports two selectable modes: dimming mode for smoothly controlling up to 100 DC controlled fluorescent dimming ballasts or compatible LED systems, and shade control mode for line voltage shade motors. This controller is suitable for electrical distributors and lighting solutions providers seeking reliable wire and cable-compatible dimming and control devices. Auxiliary power packs are required for operation. It includes a sensor input for automatic occupancy-based lighting control, enhancing energy efficiency in commercial and institutional environments.

Specifications

• Input Voltage: 24VDC, 35mA
• Control Output for 0-10VDC Ballasts: Sinks up to 50mA; maximum voltage 9.5VDC, minimum voltage 0.5VDC
• Two Outputs for External Maintained Relays
• Dimensions: 2.64” (H) x 1.75” (W) x 1.98” (D); depth in wall 1.65”
• Operating Conditions: Indoor use only; 32-104°F (0-40°C); 0-80% RH, non-condensing
• UL and cUL Listing Pending
• Product Weight: 2.9 lbs
• Color: Ivory
• Five Year Warranty

Features

• Controls low voltage 0-10V lighting loads or line voltage shades
• Compatible with decorator wall plates including radiant® screwless or standard styles
• Recalls last-used light level (preset)
• Two-second fade rate for smooth dimming transitions
• Input for occupancy sensors or photosensors enabling automatic operation
• Long-life status LED for operational feedback
• Easy-to-use paddle interface with manual raise/lower and preset recall
• Power failure restores to last-used level
• Manual On requires a momentary switch and power pack with manual on capability
• Not compatible with BZ-250 power pack
