Copper YS31L Compression Splice – Wire Splice Solutions

The Copper YS31L is a compression copper reducer/splice designed for reliable wire splicing applications. It is suitable for electrical distributors and switchgear suppliers requiring durable connections in wire and cable systems. This splice supports conductor sizes of 350 thousand circular mils and operates at a maximum voltage of 35,000 volts. It is electro-tin plated to ensure corrosion resistance and optimal conductivity, making it a dependable component in lighting solutions and electrical distribution networks.

Specifications

• Application: Wire Splice
• Material: Copper
• Finish: Tin-Plated
• Conductor Size: 350 thousand circular mils
• Max. Voltage: 35000 volts
• Color: Black
• Color Coding: Red
• Product Weight: 0.1700 lbs
• CSA Certified: Yes
• Manufacturer: Burndy
• Manufacturer Part #: YS31L

Features

• Compression type copper splice for secure electrical connections
• Standard barrel design suitable for 350 kcmil stranded conductors
• Electro-tin plating enhances corrosion resistance and electrical performance
• Rated for high voltage applications up to 35kV

Downloads & Links

• Prop 65 Notice
• YS31L_MODEL-IGES
• SD022390-01
• Spec Sheet
• YS31L_MODEL-STEP
• YS31L_MODEL-PDF
