Copper YS1CLBOX Compression Splice for Wire Splice Applications

The Copper YS1CLBOX is a compression copper reducer/splice designed for wire splice applications, suitable for electrical distributors and wire and cable suppliers requiring reliable connections. It features a standard barrel style optimized for limited space applications, offering ample barrel length for proper crimping. This product is ideal for use in electrical systems requiring insulation ratings from 600V up to 35kV.

Specifications

• Application: Wire Splice
• Material: Copper
• Finish: Tin-Plated (Electro Plated)
• Color: Black
• Color Coding: Green
• Conductor Size: 1 American Wire Gauge (AWG)
• Max. Voltage: 35,000 volts
• Product Weight: 0.0400 lbs
• Barrel Style: Chamfered
• Barrel Type: Standard
• Length Overall: 2.06 inches (52 mm)
• Outside Diameter: 0.46 inches
• Strip Length: 15/16 inches
• CSA Approved: Yes
• UL Listed: Yes
• Industry Standards Met: UL468A-468B

Features

• Standard barrel length designed for limited space applications
• Four center conductor stops for proper conductor insertion
• Tin plating provides corrosion resistance and reliable conductivity
• Compatible with commercial stranded copper conductors
• Chamfered barrel style facilitates easier cable insertion
• Meets CSA and UL certification requirements
