Morris Products
Copper Short Barrel Compression Splices #8
SKU: #279458
Part: #94410
UPC: 601986944106
Morris Products
Copper Short Barrel Compression Splices #8
SKU: #279458
Part: #94410
UPC: 601986944106
Description
Copper Short Barrel Compression Splices #8 – Electrical Wire and Cable Connector
The Copper Short Barrel Compression Splice #8 is designed for electrical distributors and switchgear suppliers requiring reliable wire connection solutions. Manufactured from high conductivity seamless copper tubing, this compression splice ensures optimal electrical performance for wire sizes ranging from #8 stranded through 1000 MCM. It is suitable for applications in lighting solutions and general electrical wiring where secure, durable splices are essential.
Specifications
- Material: High Conductivity Seamless Copper Tubing
- Material Treatment: Electro-Tin Plating
- Wire Size Range: #8 Stranded through 1000 MCM
- Temperature Rating: 90°C
- Voltage Rating: 35 kV
- Color Coding: Red
- Inside Diameter: 0.173 inches
- Outside Diameter: 0.272 inches
- Product Weight: 0.0180 lbs
- Manufacturer Part Number: 94410
- UPC: 601986944106
Features
- Manufactured from high strength, high conductivity seamless copper tubing
- Electro-tin plated for corrosion resistance
- Color coded and marked with die size and crimp marks for easy identification
- UL Listed to UL486A standard
- cUL and RoHS compliant
