Copper Short Barrel Compression Splices #6 – Electrical Wire Connectors
The Copper Short Barrel Compression Splices #6 are designed for reliable electrical connections in wire and cable installations. Manufactured by Morris Products, these compression splices serve as essential components for electrical distributors and lighting solutions providers requiring high-quality connectors for wire sizes ranging from #8 stranded through 1000 MCM. Their robust construction and precise dimensions support secure, conductive terminations in various electrical systems.
Specifications
- Material: High Conductivity Seamless Copper Tubing
- Material Treatment: Electro-Tin Plating
- Wire Size: #8 Stranded through 1000 MCM
- Temperature Rating: 90°C
- Voltage Rating: 35 kV
- Color Coding: Blue
- Inside Diameter: 0.203 inches
- Outside Diameter: 0.297 inches
- Product Weight: 0.0290 lbs
- Manufacturer Part Number: 94412
- UPC: 601986944120
Features
- Manufactured from high strength, high conductivity seamless copper tubing
- Electro-tin plated for enhanced corrosion resistance
- Color coded and marked with die size and crimp marks for easy identification and installation accuracy
