Morris Products
Copper Short Barrel Compression Splices 250 MCM
SKU: #279491
Part: #94428
UPC: 601986944281
Morris Products
Copper Short Barrel Compression Splices 250 MCM
SKU: #279491
Part: #94428
UPC: 601986944281
Next day delivery
Description
Copper Short Barrel Compression Splices 250 MCM – Electrical Wire Connector
The Copper Short Barrel Compression Splice 250 MCM is designed for reliable electrical connections in wire and cable applications. Manufactured by Morris Products, this splice is suitable for use by electrical distributors and switchgear suppliers requiring high conductivity and secure compression splicing for large conductor sizes up to 1000 MCM. It is electro-tin plated for corrosion resistance and color coded for easy identification.
Specifications
- Material: High Conductivity Seamless Copper Tubing
- Wire Size Range: #8 Stranded through 1000 MCM
- Temperature Rating: 90°C
- Voltage Rating: 35 KV
- Color Coding: Yellow
- Inside Diameter: 0.594 inches
- Outside Diameter: 0.750 inches
- Product Weight: 0.1810 lbs
- UL Certification: UL486A
- cUL: Yes
- RoHS Compliant: Yes
Features
- Manufactured from high strength, high conductivity seamless copper tubing
- Electro-tin plated for enhanced corrosion resistance
- Color coded and marked with die size and crimp marks for ease of installation
