Morris Products
Copper Long Barrel Compression Splices #8
SKU: #279520
Part: #94510
UPC: 601986945103
Morris Products
Copper Long Barrel Compression Splices #8
SKU: #279520
Part: #94510
UPC: 601986945103
Description
Copper Long Barrel Compression Splices #8 – Electrical Wire Connector
The Copper Long Barrel Compression Splices #8 are designed for secure electrical connections in wire and cable applications. Manufactured from high conductivity seamless copper tubing and electro-tin plated for enhanced performance, these compression splices are suitable for use by electrical distributors and switchgear suppliers requiring reliable wire splicing solutions. The product is color-coded red for easy identification and marked with die size and crimp marks to ensure proper installation.
Specifications
- Material: High Conductivity Copper
- Wire Size Range: #8 Stranded through 1000 MCM
- Temperature Rating: 90°C
- Voltage Rating: 35 KV
- Color Coding: Red
- Inside Diameter: 0.172 inches
- Outside Diameter: 0.272 inches
- Product Weight: 0.0340 lbs
- Manufacturer Part #: 94510
- Certifications: UL486A, cUL, RoHS Compliant
Features
- Manufactured from high strength, high conductivity seamless copper tubing
- Electro-tin plated for corrosion resistance and improved conductivity
- Color coded and marked with die size and crimp marks for accurate installation
