Copper Long Barrel Compression Splices 500 MCM
SKU: #279597
Part: #94536
UPC: 601986945363
Copper Long Barrel Compression Splices 500 MCM
SKU: #279597
Part: #94536
UPC: 601986945363
Total Price: $25.67 per piece Sold in increments of 1 piece
Description
Copper Long Barrel Compression Splices 500 MCM – Electrical Wire Splice Connector
The Copper Long Barrel Compression Splices 500 MCM are designed for reliable electrical connections in wire and cable applications. Manufactured from high conductivity seamless copper tubing with electro-tin plating, these splices ensure high strength and excellent conductivity for industrial and commercial electrical distribution. Suitable for use by electrical distributors and switchgear suppliers, they support wire sizes from #8 stranded through 1000 MCM, providing secure, color-coded compression connections for lighting solutions and power distribution systems.
Specifications
- Material: High Conductivity Copper
- Color Coding: Brown
- Inside Diameter: .835 inches
- Outside Diameter: 1.063 inches
- Temperature Rating: 90°C
- Voltage Rating: 35 kV
- Wire Size Range: #8 Stranded through 1000 MCM
- Material Treatment: Electro-Tin Plating
- Product Weight: 0.7220 lbs
- Certifications: UL486A, cUL, RoHS Compliant
Features
- Manufactured from high strength, high conductivity seamless copper tubing
- Electro-tin plated for corrosion resistance
- Color coded and marked with die size and crimp marks for easy identification
