Morris Products
Copper Long Barrel Compression Splices 400 MCM
SKU: #279587
Part: #94534
UPC: 601986945349
Morris Products
Copper Long Barrel Compression Splices 400 MCM
SKU: #279587
Part: #94534
UPC: 601986945349
Next day delivery
Description
Copper Long Barrel Compression Splices 400 MCM – Electrical Wire Connectors
This Copper Long Barrel Compression Splice is designed for secure electrical connections in wire and cable installations. Manufactured from high conductivity seamless copper tubing with electro-tin plating, it ensures reliable conductivity and corrosion resistance. Suitable for wire sizes ranging from #8 stranded through 1000 MCM, this splice is commonly used by electrical distributors and switchgear suppliers in various industrial and commercial lighting solutions and power distribution applications.
Specifications
- Material: High Conductivity Seamless Copper Tubing
- Temperature Rating: 90°C
- Voltage Rating: 35 KV
- Wire Size Range: #8 Stranded through 1000 MCM
- Material Treatment: Electro-Tin Plating
- Inside Diameter: 0.764 inches
- Outside Diameter: 0.949 inches
- Color Coding: Blue
- Product Weight: 0.5220 lbs
- Manufacturer Part Number: 94534
- Certifications: UL 486A, cUL, RoHS Compliant
Features
- Manufactured from high strength, high conductivity seamless copper tubing
- Electro-tin plated for enhanced corrosion resistance
- Color-coded and marked with die size and crimp marks for easy identification and installation
