Morris Products
Copper Long Barrel Compression Splices #4
SKU: #279527
Part: #94514
UPC: 601986945141
Morris Products
Copper Long Barrel Compression Splices #4
SKU: #279527
Part: #94514
UPC: 601986945141
Next day delivery
Description
Copper Long Barrel Compression Splices #4 – Electrical Wire Splice Connectors
The Copper Long Barrel Compression Splice #4 is designed for secure electrical connections in wire and cable applications. Manufactured by Morris Products, this splice is suitable for use by electrical distributors and switchgear suppliers requiring reliable, high conductivity copper splices for wire sizes ranging from #8 stranded through 1000 MCM. Its construction supports efficient electrical conductivity and mechanical strength in lighting solutions and general electrical wiring installations.
Specifications
- Material: High Conductivity Seamless Copper Tubing
- Material Treatment: Electro-Tin Plating
- Wire Size Range: #8 Stranded through 1000 MCM
- Temperature Rating: 90°C
- Voltage Rating: 35 KV
- Color: Gray
- Inside Diameter: 0.250 inches
- Outside Diameter: 0.344 inches
- Length: 2.36 inches
- UL Certification: UL486A
- cUL: Yes
- RoHS Compliant: Yes
- Product Weight: 0.0500 lbs
Features
- Manufactured from high strength, high conductivity seamless copper tubing
- Electro-tin plated for corrosion resistance
- Color coded and marked with die size and crimp marks for easy identification and installation accuracy
