Copper Long Barrel Compression Splices #2
SKU: #279530
Part: #94516
UPC: 601986945165
Copper Long Barrel Compression Splices #2
SKU: #279530
Part: #94516
UPC: 601986945165
Total Price: $5.70 per piece Sold in increments of 1 piece
Description
Copper Long Barrel Compression Splices #2 – Electrical Wire and Cable Connector
The Copper Long Barrel Compression Splice #2 by Morris Products is designed for secure electrical connections in wire and cable applications. Manufactured from high conductivity seamless copper tubing, this compression splice is suitable for electrical distributors and lighting solutions requiring reliable conductor splicing. It supports wire sizes from #8 stranded through 1000 MCM and is electro-tin plated for enhanced conductivity and corrosion resistance.
Specifications
- Material: High Conductivity Copper
- Wire Size Range: #8 Stranded through 1000 MCM
- Temperature Rating: 90°C
- Voltage Rating: 35 kV
- Color Coding: Brown
- Inside Diameter: 0.315 inches
- Outside Diameter: 0.422 inches
- Length: 2.60 inches
- Manufacturer Part Number: 94516
- Product Weight: 0.0770 lbs
- Certifications: UL 486A, cUL, RoHS Compliant
Features
- Manufactured from high strength, high conductivity seamless copper tubing
- Electro-tin plated for corrosion resistance and improved electrical performance
- Color coded and marked with die size and crimp marks for easy identification
