Copper Long Barrel 2 Hole Compression Lugs #8 Awg 1/4 Stud 5/8" Spacing - Electrical Wire Termination

This copper long barrel compression lug is designed for reliable electrical cable terminations, suitable for use by electrical distributors and switchgear suppliers. It accommodates wire sizes from #8 stranded through 750 MCM and features a 2-hole stud configuration with 1/4" stud size and 5/8" hole spacing. The lug is ideal for applications requiring durable, high-conductivity connections in lighting solutions and wire and cable installations.

Specifications

• Material: High Conductivity Copper
• Wire Size Range: #8 Stranded through 750 MCM
• Stud Configuration: 2 Hole
• Stud Size: 1/4"
• Stud Spacing: 5/8"
• Temperature Rating: 90¬∞C
• Voltage Rating: 35 KV
• Color Coding: Red
• Product Weight: 0.0350 lbs
• Certifications: UL486A, cUL, RoHS Compliant

Features

• Manufactured from high strength, seamless copper tubing for superior conductivity
• Electro-tin plated for corrosion resistance
• Color coded and marked with die size and crimp marks for easy identification
• Includes peep hole for inspection of proper conductor insertion

Downloads & Links

• Spec Sheet
