Morris Products
Copper Long Barrel 2 Hole Compression Lugs 600 MCM 1/2 Stud 1-3/4" Spacing
SKU: #279436
Part: #94394
UPC: 601986943949
Morris Products
Copper Long Barrel 2 Hole Compression Lugs 600 MCM 1/2 Stud 1-3/4" Spacing
SKU: #279436
Part: #94394
UPC: 601986943949
Description
Copper Long Barrel 2 Hole Compression Lugs 600 MCM 1/2 Stud 1-3/4" Spacing - Compression Lugs
This copper long barrel 2 hole compression lug is designed for reliable electrical cable terminations in wire and cable applications. Manufactured from high conductivity seamless copper tubing, it provides efficient electrical connectivity suitable for electrical distributors and switchgear suppliers requiring robust lighting solutions and cable connections.
Specifications
- Material: High Conductivity Copper
- Wire Size: #8 Stranded through 750 MCM
- Stud Configuration: 2 Hole
- Stud Size: 1/2"
- Stud Spacing: 1-3/4"
- Temperature Rating: 90°C
- Voltage Rating: 35 KV
- Flammability Rating: N/A
- Amp Rating: To Conductor
- Color: Green
- Product Weight: 1.35 lbs
- Certifications: UL486A, cUL, RoHS Compliant
Features
- Manufactured from high strength, high conductivity seamless copper tubing
- Electro-tin plated for enhanced corrosion resistance
- Color coded and marked with die size and crimp marks for easy identification
- Peep hole for inspection of proper cable insertion
