Morris Products
Copper Long Barrel 2 Hole Compression Lugs #6 Awg 3/8 Stud 7/8" Spacing
SKU: #279674
Part: #94557
UPC: 601986945578
Morris Products
Copper Long Barrel 2 Hole Compression Lugs #6 Awg 3/8 Stud 7/8" Spacing
SKU: #279674
Part: #94557
UPC: 601986945578
Description
Copper Long Barrel 2 Hole Compression Lugs #6 Awg 3/8 Stud 7/8" Spacing – Electrical Wire and Cable Connector
This copper long barrel 2 hole compression lug is designed for fast, reliable electrical cable terminations. Manufactured by Morris Products, it is suitable for use by electrical distributors and switchgear suppliers requiring high conductivity and durable cable connectors in lighting solutions and wire and cable installations.
Specifications
- Material: High Conductivity Copper
- Stud Configuration: 2 Hole
- Stud Size: 3/8"
- Stud Spacing: 7/8"
- Wire Size Compatibility: #8 Stranded through 750 MCM
- Temperature Rating: 90°C
- Voltage Rating: 35 KV
- Material Treatment: Electro-Tin Plated
- Color Coding: Blue
- Certification: UL UL486A, cUL, RoHS Compliant
- Product Weight: 0.0360 lbs
Features
- Manufactured from high strength, high conductivity seamless copper tubing
- Electro-tin plated for corrosion resistance
- Color coded and marked with die size and crimp marks for easy identification
- Includes peep hole for inspection of proper crimping
