Morris Products
Copper Long Barrel 2 Hole Compression Lugs 400 MCM 5/8 Stud 1-3/4" Spacing
SKU: #279731
Part: #94579
UPC: 601986945790
Morris Products
Copper Long Barrel 2 Hole Compression Lugs 400 MCM 5/8 Stud 1-3/4" Spacing
SKU: #279731
Part: #94579
UPC: 601986945790
Description
Copper Long Barrel 2 Hole Compression Lugs 400 MCM 5/8 Stud 1-3/4" Spacing – Electrical Cable Termination Solutions
This Copper Long Barrel 2 Hole Compression Lug is designed for fast and reliable electrical cable terminations, suitable for use in wire and cable applications within electrical distribution and lighting solutions. Manufactured by Morris Products, it is engineered to provide secure connections for heavy gauge cables up to 750 MCM, making it ideal for switchgear suppliers and electrical distributors requiring high-quality compression connectors.
Specifications
- Material: High Conductivity Copper
- Stud Configuration: 2 Hole
- Stud Size: 5/8"
- Stud Spacing: 1-3/4"
- Wire Size Range: #8 Stranded through 750 MCM
- Temperature Rating: 90°C
- Voltage Rating: 35 kV
- Material Treatment: Electro-Tin Plated
- Color Coding: Blue
- Product Weight: 0.5420 lbs
- Certifications: UL486A, cUL, RoHS Compliant
Features
- Manufactured from high strength, high conductivity seamless copper tubing
- Electro-tin plating for corrosion resistance
- Color coded and marked with die size and crimp marks for easy identification
- Includes peep hole for visual inspection of cable insertion
