Morris Products
Copper Long Barrel 2 Hole Compression Lugs 400 MCM 3/8 Stud 1" Spacing
SKU: #279414
Part: #94385
UPC: 601986943857
Morris Products
Copper Long Barrel 2 Hole Compression Lugs 400 MCM 3/8 Stud 1" Spacing
SKU: #279414
Part: #94385
UPC: 601986943857
Description
Copper Long Barrel 2 Hole Compression Lugs 400 MCM 3/8 Stud 1" Spacing - Electrical Wire and Cable Connector
This Copper Long Barrel 2 Hole Compression Lug is designed for fast, reliable electrical cable terminations. Manufactured from high conductivity seamless copper tubing, it is suitable for wire sizes ranging from #8 Stranded through 750 MCM. Ideal for electrical distributors and lighting solutions providers requiring durable and efficient connectors, this lug supports a 3/8" stud size with 1" spacing, ensuring secure and stable connections in switchgear and other electrical installations.
Specifications
- Material: High Conductivity Copper
- Stud Configuration: 2 Hole
- Stud Size: 3/8"
- Stud Spacing: 1"
- Wire Size Range: #8 Stranded through 750 MCM
- Temperature Rating: 90°C
- Voltage Rating: 35 KV
- Material Treatment: Electro-Tin Plating
- Color Coding: Blue
- Product Weight: 1.2 lbs
- Certifications: UL486A, cUL, RoHS Compliant
Features
- Manufactured from high strength, high conductivity seamless copper tubing
- Electro-tin plated for enhanced corrosion resistance
- Color coded and marked with die size and crimp marks for easy identification
- Includes peep hole for inspection of proper cable insertion
